Crystal Structure, Fe3+ Luminescence Sensing and Color Tuning  of 2D Lanthanide-metal-organic Frameworks Constructed  from Tricarboxylic Acid Ligand

PAN Meng-Qi, YANG Run-Qi, MUHAMMAD Yaseen, CAI Kun-Tong, HAN Feng, ZHANG Hao-Chen, NIU Yuan-Qing and WANG Hao*

Chin. J. Struct. Chem. 2022, 41, 2202023-2202033  DOI: 10.14102/j.cnki.0254-5861.2011-3243

February 15, 2022

lanthanide metal-organic frameworks, sensing, luminescence, Fe3+, color tuning

ABSTRACT

A new lanthanide metal-organic framework (MOF) [Eu(BTB)(phen)(DMF)]DMF (1, DMF = N,N-dimethylformamide) was synthesized using H3BTB (1,3,5-tri(4-carboxyphenyl)benzene) and phen (1,10-phenanthroline) under solvothermal conditions. The structure of the prepared MOF was characterized by single-crystal X-ray diffraction analyses, elemental analysis, fluorescence spectrum, FT-IR spectroscopy, powder X-ray diffraction and thermogravimetric analyses. The structure of 1 can be viewed as a 3-D supramolecular network, which is formed by the stacking of 2D layers through π-π interaction. The luminescence explorations revealed that 1 possesses favorable selectivity and sensitivity for testing Fe3+. Additionally, color tuning was achieved by varying Eu3+:Tb3+ ratios in the reaction mixtures.
